hw-tfc-450-x
selective coater
application scope:pcb board,mobile phone,3c digital,smart wearable device,semiconductor chip,new energy,led industry,life science,medical care,etc.
product features
1、the frame adopts full sheet metal welding design, beautiful appearance and stable operation;
2、using industrial computer control,windows 7 operating system is more convenient,more humanized;
3、it can be programmed online or offline;
4、with automatic accuracy calibration function,high operation accuracy;
5、adopt imported pneumatic components for control;
6、the atomization adjustment adopts precision pressure regulating valve,which can evenly control the atomization air flow and improve the edge clarity;
7、reserved exhaust gas emission collection port to better protect the working environment;
8、has the function of low pressure protection,can effectively prevent low air pressure and damage to machines and workpieces;
9、the equipment is equipped with an online automatic signal connection port;
10、pneumatic regulation filter has automatic drainage function;
11、with low air pressure report function, more safe;
12、high speed,mute effect is good,that is, can work on the board at the same time, and can spray the board,
13、the conveying belt is intelligent controlled by 2 speeds and sock back;
14、with intelligent automatic identification of on-line front and back.
technical parameter
frack dimensions l*w*h | l1060mm*w1300mm*h1680mm |
weight | 720kg |
control mode | ndustrial control machineboard card |
operation mode | computerized control |
programming mode | visual programming |
number of running program stores | over 1,000 units |
pcb transmission height | 900±20mm |
travelling speed | 0-3500mm/min adjustable |
transfer direction | l-r（r-l） |
transmission motor power | ac220v 40w |
pcb width range | singleboard50-450mm, spareplate50-200mm |
adjust the way | manual regulation |
x.y axis drive mode | yaskawaservomotorhighprecisionwirerod,guiderail |
x.y axis maximum running speed | 500mm/s |
x.y axis positioning accuracy | ±0.02mm |
z axis maximum running speed | 500mm/s |
z axis drive mode | yaskawaservomotorhighprecisionwirerodmodule |
z axis positioning accuracy | 0.02mm |
rubber valve up and down | 2smc two-rod cylinder drive |
number of glue valve | 2个 |
type of glue valve | 1dispensing valve,1precision tapered valve |
pcb plate size | max：w450mm*l450mm |
pcb plate component height | max90mm |
needledispensingvalve coatingwidth | minimum coating width:2mm |
needledispensingvalvenozzlesize | optional type |
marginal definition | ±1mm |
fine mist flower coating width | single coating width:6-8mm |
cover thickness | 0.03mm-1mm |
quantity of bucket | onethree-proofpaintpressurebucketonecleaningbucket(optional) |
cleaning function | the equipment has its own cleaning function |
lighting part | the equipment has its own lighting light source |
detection part | the equipment has its own uv detection light source |
power | ac220v |
air supply | 0.2~0.6mpa |
aggregate capacity | 2.5kw |
