desktop coater-ag亚洲国际厅

application: pcb board, mobile phone, 3c digital, smart wearable devices, semiconductor chips, new energy, led industry, life science, medical, etc.

hw-tfa-5441




desktop-type coader


application scope: pcb board, mobile phone, 3c digital,smart wearable device,semiconductor chip,new energy, led industry, life science,medical care,etc.


product  features


1、the frame adopts high - grade aluminum profile design,  beautiful appearance and easy to maintain;

2、using the control card handle control,  the operation is simpler;

3、with the function of automatic needle calibration, high operation accuracy;

4、with the front and rear of the four directions of selective coating function;

5、zero  adjustment  using  precision  pressure regulating valve,  can balance control atomization airflow, improve the edge cleanliness;

6、strong  compatibility,  can  better cooperate  with various sizes of pcb board,  to achieve the best coating effect;

7、reserved waste discharge collection outlets to better protect the working environment;

8、pneumatic regulation filter has automatic drainage function;

9、size 2 valve design,  more practical,  higher coating accuracy.


technical parameter


  frack dimensions l*w*h

    l820mm*w688mm*h829mm

  weight

    150kg

mode of operation

control card control handle

number of running program stores

over 1,000 units

 transfer weight

10 kg for xy axis and 5 kg for z axis

pcb width range

singleboard50-450mm, spare plate50-200mm (50-300)

adjusting mode

manual regulation

x.y axis drive mode

rse stepper motor(optional)

x.yaxismaximumrunning speed

    500mm/s

x.y axis positioning accuracy

    ±0.02mm

z axis drive mode

 resay stepper motor(optional)

z axis positioning accuracy

    0.02mm

rubber valve up and down

2 rod cylinder drive

number of glue valve

  2     two

type of glue valve

1 dispensing valve, 1 precision spray valve

pcb plate component height

  max90mm

needledispensingvalvecoatingwidth

minimum coating width:2mm

needledispensingvalvenozzlesize

optional type

cover thickness

  0.03mm-1mm

quantity of bucket

 athreeproofpaintpressurebucketacleaningbucket

cleaning function

the device has the cleaning function

power

  ac220v

air supply

  0.2~0.6mpa

aggregate capacity

  2.5kw
