the panoramic vision laser cleaning machine is an efficient and environmentally friendly cleaning equipment that combines laser technology and panoramic vision system to accurately locate and remove surface dirt, coatings, or rust. this type of device is widely used in various industries, such as automobiles, aviation, electronics, and manufacturing, providing a fast, non-destructive, and controllable cleaning solution.
hw-djb8308
panoramic vision laser cleaning machine
scope of application: metal surface rust removal, surface paint removal, surface oil stains, stains, dirt cleaning, surface coating, coating cleaning, welding surface, spray surface, stone surface dust and attachments removal, rubber mold residue cleaning, antique and cultural relic cleaning, etc.
product features
1. adopting panoramic visual alignment system and high-precision visual positioning system for automatic recognition;
2. no need for precision fixtures, marking can be done directly;
3. original imported isolator protects fiber laser, enhances stability and laser lifespan;
4. can automatically identify defective products or products that do not require labeling, saving production costs;
5. efficient and stable, 2-3 times higher than traditional marking machines
technical parameter
project | working area | 400mm* 300mm(dual platform) |
x,y,z | maximum operating speed | 1000mm/s |
operating accuracy | ±0.02mm | |
driving method | panasonic servo motor upper silver precision screw upper silver precision guide rail | |
effective travel | 400mm* 300mmx*80mm | |
laser head | number of lasers | 1 standard configuration |
laser power | 60w | |
vision system | marking efficiency | 1800/uph (dots) |
marking accuracy | ±0.1mm | |
vision system | camera positioning | 2 sets of 20 million pixel cameras, with cameras selected according to product features |
light source | matrix smd-led light source | |
operating system | control | pc motion control card |
software | homemade chinese professional visual software compatible with win7 | |
programming | direct camera recognition | |
other | scalability (optional) | 1. scalable online operation modes such as smt conveyor belts and conveyor belts 2. laser altitude measurement (sick) |
power supply power | ac220v,1200w | |
working air pressure | 0.5mpa ~0.8mpa | |
external dimensions | 1380mm(width) x1400mm(depth) x1920mm(height) | |
laser parameters | maximum laser power: 60w laser wavelength: 1064nm) laser repetition frequency: 20khz-100khz engraving line speed: ≤ 8000mm/s) minimum line width: 0.01mm standard engraving range: 100mm x 100mm) optional engraving range: 70mmx70mm, 160mmx160mm) minimum character: 0.15mm power consumption: ≤ 1000w) cooling method: air cooling repeated accuracy: ± 0.02mm) power demand: 220v ± 10%/50hz/5a | |
laser configuration | fiber laser: ruike 60w f-q lens: focal length: 150mm beam expander: 5x galvanometer: 1064 jiate | |
