product features:

1. the ab dual liquid dispensing machine uses a screw pump or gear pump combined with a stepper motor to precisely control the rotation speed and angle of the pump to accurately mix ab glue,the dispensing accuracy reaches plus or minus 2%, with flexible and on-demand dispensing, allowing for maximum adhesive savings while mixing;

2. accurate dispensing: imported gear pump is selected, equipped with ab glue level alarm function, which can timely prevent the occurrence of glue breakage,the b glue curing agent is also equipped with a glue quantity monitoring device to prevent the problem of glue not drying due to the breakage of b glue;

3. multi filtration system: the glue is filtered from the barrel to the dispensing head using multiple filters to prevent impurities from entering the barrel and causing pump jamming;

4. heating devices can be added, equipped with ab bucket mixing equipment to prevent sedimentation;

5. easy to clean: the machine adopts a liquid separation and packaging method, only mixing at the dispensing head. after use, remove the mixing tube and soak it in the cleaning solution or clean it directly;

6. integrated design of dispensing and dispensing, with on-demand and fully automatic operation;

7. easy to operate, can store 10 sets of parameters, and call up product parameters during production by pressing the start button.

technical parameters:

1. frame dimensions: l * w * h l1300mm * w1000mm * h1300mm

2. effective work itinerary: 500 * 500 * 100 (itinerary can be customized)

3. repetitive motion accuracy: plus or minus 0.02mm

4. control system: handheld programming box 7-inch touch screen

5. cleaning method: automatic cleaning

6. mixing method: dynamic mixing or static mixing

7. glue supply method: gear pump/guide rod pump (optional)

8. use adhesive viscosity: 300cps-3000cps (viscosity can be reduced by stirring and heating)

9. rubber ratio range: adjustable from 10:1 to 10:10

10. glue metering pump body: precision screw pump, gear pump

11. glue dispensing accuracy: plus or minus 2%

12. material storage cylinder selection: 15l, 20l, 30l, 40l, etc

13. scope of gluing: epoxy resin/polyurethane/organosilicon, etc

14. ab glue vacuum pumping: optional

15. working parameters: voltage, ac220v, 50hz, working pressure 0.4-0.8mpa

application scope:

application scope: automotive parts, electronic components, medical equipment, communication equipment, home appliances, plastic toys, instrument electrical. can be used for general purposesmobile phone case, power adapter, pcb electronic products, electronic small devices, mobile phone board, battery box, small household appliances, router,plug in, power supply, toy wheels, car parts assembly.
